*Characteristics:

- Volume of processed smoke (m2/h) 25 ~ 40 * 104---150 ~ 210 * 104

- Smoke temperature (130 ~ 170 ℃) - 130 ~ 200

- Smoke resistance loss (Pa) <300

- Electric field smoke velocity (m/S) 0.9 ~ 1.1---1.0 ~ 1.4

- Air leakage rate (%) <5

- Effective area of electric field (m2) 55 ~ 110--- 190 ~ 230

- Homopolar spacing (mm) 300 ~ 410

- Electric field length (m) 9 ~ 10.5-- 12 ~ 8

- Working pressure (Pa) -3000 ~ 4500 --- 5000 ~ 6500

- Weight (T) 280 ~ 350 -- 1200 ~ 1500

?- Dust removal efficiency (%) >98- ->98-99

*Applications:

Cement, coal mining

?

Description:

General electrostatic precipitator flue gas flow direction perpendicular to the power line, after the flue gas velocity on dust charged to the electrode moving speed has no direct impact. The flow direction and power line of the flue gas of the horizontal electrost
